FR210 BOPP adhesive gum tape making machine

PDF    Inquiry

• Description

• Application

  Suitable for the stripping of BOPP sealing tape / cellophane tape.

  Feature

  1. It adopts four 6 automatic exchange coiling and continuous winding to improve work efficiency.
  2. PLC control system, touch screen operation.
  3. Variable frequency stepless speed regulation, equipped with three-stage counter, can automatically decelerate and stop when running at high speed.
  4. The unwinding tension is controlled by pneumatic brakes. The winding tension is double-controlled. It is equipped with a clutch and reel independent sliding device, which can adjust the tension freely.
  5. Configure the curved spreader roller to effectively stretch the substrate.
  6. (Optional) automatic labeling function, hydraulic feeding mechanism, soundproof cover mechanism, air knife mechanism.



  Finished products





  Parameter

  Model	FR210

  Model	FR210
  Effective width	1320 mm (1620mm optional)
  Maximum unwinding diameter	800mm
  Minimum slit width	10mm
  Maximum winding diameter (1" axis) four-axis exchange	75mm
  Maximum winding diameter (3" axis) four-axis exchange	180mm
  Maximum winding diameter (3" axis) two-axis exchange	300mm
  Speed	0-180m/min
  Knives	0.2×22×60mm
  Power	5.5HP
  After-sales Service Provided	24h Online Engineers Service
